The 5/8" x 1/2" Female Inverted Flare x Male Iron Pipe 90 deg Elbow is a versatile fitting designed to create a 90-degree connection between pipes or hoses. With a female inverted flare on one end and a male iron pipe thread on the other, this elbow ensures a secure, leak-proof seal for fluid and gas systems. It is ideal for use in hydraulic, fuel line, and pneumatic applications, offering a reliable solution for tight spaces where a 90-degree turn is necessary.
|
Specification |
Details |
|
TYPE |
Female Inverted Flare x Male Iron Pipe Elbow |
|
DESIGN |
90-Degree Elbow to connect a tube with an inverted flare fitting to a threaded pipe fitting at a right angle. |
|
MATERIAL |
Brass for durability, corrosion resistance, and compatibility |
|
MATERIAL CONSTRUCTION |
Brass |
| ADDITIONAL INFORMATION |
0.67 x 1.29" Center to End |
| TUBE WALL |
0.035" |
| WEIGHT (LBS) |
0.180 |
|
CONNECTION SIZE 1 |
5/8" |
|
CONNECTION SIZE 2 |
1/2" |
|
CONNECTION TYPE |
Female Inverted Flared|MNPT |
|
CONNECTION TYPE 1 |
Female Inverted Flared |
|
CONNECTION TYPE 2 |
MNPTF |
|
FOR USE WITH |
Aluminum, Brass, Copper, and Steel Hydraulic Tubing |
|
FITTING TYPE |
90 deg Elbow |
|
MAXIMUM OPERATING PRESSURE |
650 psi |
|
OPERATING TEMPERATURE |
-65 to 250 deg F |
|
THREAD SIZE |
7/8-18 x 1/2-14 |
|
SAE # |
040202 |
|
APPLICATIONS |
Ideal for hydraulic systems, fuel lines, pneumatic systems. |
|
BRAND |
Midland Industries |
Link to Midland Industries Catalog
The 5/8" x 1/2" Female Inverted Flare x Male Iron Pipe 90 deg Elbow is a versatile fitting designed to create a 90-degree connection between pipes or hoses. With a female inverted flare on one end and a male iron pipe thread on the other, this elbow ensures a secure, leak-proof seal for fluid and gas systems. It is ideal for use in hydraulic, fuel line, and pneumatic applications, offering a reliable solution for tight spaces where a 90-degree turn is necessary.
|
Specification |
Details |
|
TYPE |
Female Inverted Flare x Male Iron Pipe Elbow |
|
DESIGN |
90-Degree Elbow to connect a tube with an inverted flare fitting to a threaded pipe fitting at a right angle. |
|
MATERIAL |
Brass for durability, corrosion resistance, and compatibility |
|
MATERIAL CONSTRUCTION |
Brass |
| ADDITIONAL INFORMATION |
0.67 x 1.29" Center to End |
| TUBE WALL |
0.035" |
| WEIGHT (LBS) |
0.180 |
|
CONNECTION SIZE 1 |
5/8" |
|
CONNECTION SIZE 2 |
1/2" |
|
CONNECTION TYPE |
Female Inverted Flared|MNPT |
|
CONNECTION TYPE 1 |
Female Inverted Flared |
|
CONNECTION TYPE 2 |
MNPTF |
|
FOR USE WITH |
Aluminum, Brass, Copper, and Steel Hydraulic Tubing |
|
FITTING TYPE |
90 deg Elbow |
|
MAXIMUM OPERATING PRESSURE |
650 psi |
|
OPERATING TEMPERATURE |
-65 to 250 deg F |
|
THREAD SIZE |
7/8-18 x 1/2-14 |
|
SAE # |
040202 |
|
APPLICATIONS |
Ideal for hydraulic systems, fuel lines, pneumatic systems. |
|
BRAND |
Midland Industries |
Link to Midland Industries Catalog
SKU:12068
5/8" x 1/2" Female Inverted Flare x Male Iron Pipe Elbow
- Regular price
- $14.44
- Sale price
- $14.44
- Regular price
-
