Description
The 3/8 Male Iron Pipe x 3/8 Male Iron Pipe Forged Mini Ball Valve is a compact, high-performance shutoff valve designed for fluid and gas flow control in various applications, including plumbing, pneumatic systems, fuel lines, and industrial setups. Constructed from forged brass, this valve provides superior strength and durability compared to cast alternatives. Its quarter-turn operation ensures quick and reliable shutoff, while premium sealing materials offer leak-proof performance.


Specification Value
TYPE Forged Mini Ball Valve
DESIGN Quarter-turn handle, ensures quick and reliable shutoff control
WEIGHT 0.310
BALL MATERIAL Brass for enhanced corrosion resistance and durability
BODY MATERIAL Forged Brass
CONNECTION TYPE MIP x FIP
DOMESTIC/IMPORT Import
DIMENSIONS 2.98" OAL x 1.42" H
DISC MATERIAL Brass
HANDLE MATERIAL Steel
INLET TO OUTLET LENGTH 1.9"
NOMINAL SIZE 3/8"
OPERATOR TYPE 180 deg Operational Handle
PRESSURE RATING 200 psi WOG
SEAT MATERIAL PTFE
STEM MATERIAL Brass
TEMPERATURE RATING 20 to 250 deg F
THREAD SIZE 3/8-18
TRIM MATERIAL Steel Screw/NBR O-Ring/Steel Nut
ADDITIONAL DIMENSION
 C        0.73
APPLICATIONS Ideal for Plumbing & Water Systems, Compressed Air & Pneumatic Systems, Fuel & Oil Lines, HVAC & Refrigeration,  Gas & Chemical Processing, Industrial & Mechanical Systems
BRAND Midland Industries

Description
The 3/8 Male Iron Pipe x 3/8 Male Iron Pipe Forged Mini Ball Valve is a compact, high-performance shutoff valve designed for fluid and gas flow control in various applications, including plumbing, pneumatic systems, fuel lines, and industrial setups. Constructed from forged brass, this valve provides superior strength and durability compared to cast alternatives. Its quarter-turn operation ensures quick and reliable shutoff, while premium sealing materials offer leak-proof performance.


Specification Value
TYPE Forged Mini Ball Valve
DESIGN Quarter-turn handle, ensures quick and reliable shutoff control
WEIGHT 0.310
BALL MATERIAL Brass for enhanced corrosion resistance and durability
BODY MATERIAL Forged Brass
CONNECTION TYPE MIP x FIP
DOMESTIC/IMPORT Import
DIMENSIONS 2.98" OAL x 1.42" H
DISC MATERIAL Brass
HANDLE MATERIAL Steel
INLET TO OUTLET LENGTH 1.9"
NOMINAL SIZE 3/8"
OPERATOR TYPE 180 deg Operational Handle
PRESSURE RATING 200 psi WOG
SEAT MATERIAL PTFE
STEM MATERIAL Brass
TEMPERATURE RATING 20 to 250 deg F
THREAD SIZE 3/8-18
TRIM MATERIAL Steel Screw/NBR O-Ring/Steel Nut
ADDITIONAL DIMENSION
 C        0.73
APPLICATIONS Ideal for Plumbing & Water Systems, Compressed Air & Pneumatic Systems, Fuel & Oil Lines, HVAC & Refrigeration,  Gas & Chemical Processing, Industrial & Mechanical Systems
BRAND Midland Industries

Midland Industries by Midland Industries

944110

3/8 Male Iron Pipe x 3/8 Male Iron Pipe Forged Mini Ball Valve

$15.30
$15.30
