The 3/8 x Close Black Steel Nipple is a threaded pipe fitting with NPT male threads on both ends, designed for tight connections between two female-threaded fittings in gas, steam, air, and water systems. The close length means there is minimal spacing between the threads, making it ideal for compact installations.
| Specification | Details |
|---|---|
| TYPE | Close Black Steel Nipple |
| DESIGN | Close Length Design leaves little to no exposed pipe between fittings |
| MATERIAL |
Steel for durable and cost-effective for industrial piping |
| MATERIAL CONSTRUCTION | Steel |
| BOX/CASE | 50/600 |
| WEIGHT (LBS) | 0.030 |
| APPROXIMATE WEIGHT (LBS) | 0.05 |
| CONNECTION SIZE 1 | 3/8" |
| CONNECTION SIZE 2 | 3/8" |
| CONNECTION TYPE | MPT|MPT |
| CONNECTION TYPE 1 | MPT |
| CONNECTION TYPE 2 | MPT |
| DIAMETER | 3/8" |
| DIMENSIONS STANDARDS | ANSI B1.20.1 |
| FINISH | Black |
| FITTING TYPE | Nipple |
| LENGTH | 1" |
| PRESSURE CLASS | 150 lb |
| PRESSURE RATING | 700 psi |
| SCHEDULE RATING | SCH 40 |
| TEMPERATURE RATING | -200 to 150 deg F |
| THREAD LENGTH | 0.6" |
| THREAD SIZE | 3/8-18 |
| WALL THICKNESS | 0.091" |
| NOTES | Grade B |
| APPLICATIONS |
Ideal for Gas & Oil Piping, Steam & Boiler Systems, Water & Irrigation Lines, Compressed Air Systems, Fire Protection Systems, General Industrial Use |
| BRAND | Midland Industries |
The 3/8 x Close Black Steel Nipple is a threaded pipe fitting with NPT male threads on both ends, designed for tight connections between two female-threaded fittings in gas, steam, air, and water systems. The close length means there is minimal spacing between the threads, making it ideal for compact installations.
| Specification | Details |
|---|---|
| TYPE | Close Black Steel Nipple |
| DESIGN | Close Length Design leaves little to no exposed pipe between fittings |
| MATERIAL |
Steel for durable and cost-effective for industrial piping |
| MATERIAL CONSTRUCTION | Steel |
| BOX/CASE | 50/600 |
| WEIGHT (LBS) | 0.030 |
| APPROXIMATE WEIGHT (LBS) | 0.05 |
| CONNECTION SIZE 1 | 3/8" |
| CONNECTION SIZE 2 | 3/8" |
| CONNECTION TYPE | MPT|MPT |
| CONNECTION TYPE 1 | MPT |
| CONNECTION TYPE 2 | MPT |
| DIAMETER | 3/8" |
| DIMENSIONS STANDARDS | ANSI B1.20.1 |
| FINISH | Black |
| FITTING TYPE | Nipple |
| LENGTH | 1" |
| PRESSURE CLASS | 150 lb |
| PRESSURE RATING | 700 psi |
| SCHEDULE RATING | SCH 40 |
| TEMPERATURE RATING | -200 to 150 deg F |
| THREAD LENGTH | 0.6" |
| THREAD SIZE | 3/8-18 |
| WALL THICKNESS | 0.091" |
| NOTES | Grade B |
| APPLICATIONS |
Ideal for Gas & Oil Piping, Steam & Boiler Systems, Water & Irrigation Lines, Compressed Air Systems, Fire Protection Systems, General Industrial Use |
| BRAND | Midland Industries |
SKU:57040
3/8 x Close Black Steel Nipple
- Regular price
- $3.14
- Sale price
- $3.14
- Regular price
-
