Description
The 1" Steel (Black Oxide) Hinge Shaft Collar - High Strength is designed for fast and secure shaft positioning on standard round shafts, thin-wall tubing, and split hub applications. Precision-machined from black oxide steel, it features a triple-link hinge and captive screw design that allows easy assembly, repositioning, and removal without loose screws. The smooth bore protects shaft surfaces from damage while providing reliable axial holding power similar to conventional clamp collars. Available in both steel and stainless steel options.





SPECIFICATIONS DETAILS
PART NUMBER 2L100H
TYPE High Strength
DESIGN
Precision collar design provides secure positioning and reliable mechanical performance.
MATERIAL
Steel (Black Oxide) provides strength and durability
SERIES Signature
ALLOY 1215
FINISH Black Oxide
APPROXIMATE WEIGHT 0.28 lb
COUNTRY OF ORIGIN USA
UPC CODE 662786009105
ROHS2 COMPLIANT Yes
REACH COMPLIANT Yes

DIMENSIONAL ATTRIBUTES
BORE SIZE 1 in
OUTSIDE DIAMETER 2.000 in
WIDTH 0.500 in
RECESSED SCREW Yes
SCREW SIZE 1/4-28 x 3/4 in
SCREW MATERIAL Alloy Steel
CAPACITIES
SCREW SEATING TORQUE 162 in-lb
AXIAL HOLD 1450 lb

APPLICATIONS
Ideal for power transmission, motion control, industrial machinery, automation, shaft positioning, and shaft retention.
BRAND Stafford Manufacturing







Description
The 1" Steel (Black Oxide) Hinge Shaft Collar - High Strength is designed for fast and secure shaft positioning on standard round shafts, thin-wall tubing, and split hub applications. Precision-machined from black oxide steel, it features a triple-link hinge and captive screw design that allows easy assembly, repositioning, and removal without loose screws. The smooth bore protects shaft surfaces from damage while providing reliable axial holding power similar to conventional clamp collars. Available in both steel and stainless steel options.





SPECIFICATIONS DETAILS
PART NUMBER 2L100H
TYPE High Strength
DESIGN
Precision collar design provides secure positioning and reliable mechanical performance.
MATERIAL
Steel (Black Oxide) provides strength and durability
SERIES Signature
ALLOY 1215
FINISH Black Oxide
APPROXIMATE WEIGHT 0.28 lb
COUNTRY OF ORIGIN USA
UPC CODE 662786009105
ROHS2 COMPLIANT Yes
REACH COMPLIANT Yes

DIMENSIONAL ATTRIBUTES
BORE SIZE 1 in
OUTSIDE DIAMETER 2.000 in
WIDTH 0.500 in
RECESSED SCREW Yes
SCREW SIZE 1/4-28 x 3/4 in
SCREW MATERIAL Alloy Steel
CAPACITIES
SCREW SEATING TORQUE 162 in-lb
AXIAL HOLD 1450 lb

APPLICATIONS
Ideal for power transmission, motion control, industrial machinery, automation, shaft positioning, and shaft retention.
BRAND Stafford Manufacturing







Stafford Manufacturing by Stafford Manufacturing

2L100H

1" Steel (Black Oxide) Hinged Shaft Collar - High Strength

$24.76
