The 1/4 Hose x 1/8 Male BSPT Reducing Splicer is a fitting engineered to connect and transition between different hose sizes and ensuring a secure and leak-resistant connection. With a hose barb on one end and a hose barb on the other and it is ideal for adapting smaller diameter hoses in fuel, air, water, and vacuum applications. Made from high-quality brass for long-lasting durability and corrosion resistance.
| Specification | Details |
|---|---|
| TYPE | Reducing Hose Barb Splicer |
| DESIGN | Compact Design (ideal for tight and narrow spaces) |
| MATERIAL | Brass (for durability, corrosion resistance ) |
| MATERIAL CONSTRUCTION | Brass |
|
WEIGHT (LBS) |
0.020 |
| CONNECTION SIZE 1 | 1/4" |
| CONNECTION SIZE 2 | 1/8" |
| CONNECTION TYPE | Hose|Male BSP |
| CONNECTION TYPE 1 | Hose |
| CONNECTION TYPE 2 | Male BSPT |
| DIMENSIONS | 0.37" OD x 1.5" L |
| FITTING TYPE | Adapter |
| FOR USE WITH | Hose Clamp, Similar Type Clamp or A Crimped Ferrule |
| MAXIMUM OPERATING PRESSURE | 150 psi |
| OPERATING TEMPERATURE | -40 to 160 deg F |
| BARB LENGTH | 0.97" |
| SHAPE | Straight/Connector |
| APPLICATIONS |
Ideal for Automotive & Fuel Systems, Pneumatic & Air Line Connections, Water & Fluid Transfer, Irrigation & Agriculture Systems. |
| BRAND | Midland Industries |
The 1/4 Hose x 1/8 Male BSPT Reducing Splicer is a fitting engineered to connect and transition between different hose sizes and ensuring a secure and leak-resistant connection. With a hose barb on one end and a hose barb on the other and it is ideal for adapting smaller diameter hoses in fuel, air, water, and vacuum applications. Made from high-quality brass for long-lasting durability and corrosion resistance.
| Specification | Details |
|---|---|
| TYPE | Reducing Hose Barb Splicer |
| DESIGN | Compact Design (ideal for tight and narrow spaces) |
| MATERIAL | Brass (for durability, corrosion resistance ) |
| MATERIAL CONSTRUCTION | Brass |
|
WEIGHT (LBS) |
0.020 |
| CONNECTION SIZE 1 | 1/4" |
| CONNECTION SIZE 2 | 1/8" |
| CONNECTION TYPE | Hose|Male BSP |
| CONNECTION TYPE 1 | Hose |
| CONNECTION TYPE 2 | Male BSPT |
| DIMENSIONS | 0.37" OD x 1.5" L |
| FITTING TYPE | Adapter |
| FOR USE WITH | Hose Clamp, Similar Type Clamp or A Crimped Ferrule |
| MAXIMUM OPERATING PRESSURE | 150 psi |
| OPERATING TEMPERATURE | -40 to 160 deg F |
| BARB LENGTH | 0.97" |
| SHAPE | Straight/Connector |
| APPLICATIONS |
Ideal for Automotive & Fuel Systems, Pneumatic & Air Line Connections, Water & Fluid Transfer, Irrigation & Agriculture Systems. |
| BRAND | Midland Industries |
SKU:32079
1/4 x 1/8 Reducing Hose Barb Splicer
- Regular price
- $6.61
- Sale price
- $6.61
- Regular price
-
